Learn more about this contemporary southwest oasis home with a rooftop patio. View the features of the kitchen's roomy storage and cooking space.
Welcome to our house plans featuring a single-story 3-bedroom contemporary southwest oasis house floor plan. Below are floor plans, additional sample photos, and plan details and dimensions.
Floor Plan
Main Level
2nd Floor
Additional Floor Plan Images
Southwest architectural style contemporary house with flat design roof.
Sketch of the single-story, 3-bedroom contemporary southwest oasis home’s front elevation.
Sketch of the single-story, 3-bedroom contemporary southwest oasis home’s left elevation.
Sketch of the single-story, 3-bedroom contemporary southwest oasis home’s rear elevation.
Sketch of the single-story, 3-bedroom contemporary southwest oasis home’s right elevation.
Plan Details
Dimensions
| Width: | 96′ 0″ |
| Depth: | 48′ 0″ |
| Max ridge height: | 15′ 0″ |
Garage
| Type: | Attached |
| Area: | 932 sq. ft. |
| Count: | 3 Cars |
| Entry Location: | Front |
Ceiling Heights
| First Floor / 9′ 0″ |
Roof Details
| Primary Pitch: | .25 on 12 |
| Framing Type: | Truss |
Dimensions
| Width: | 96′ 0″ |
| Depth: | 48′ 0″ |
| Max ridge height: | 15′ 0″ |
Garage
| Type: | Attached |
| Area: | 932 sq. ft. |
| Count: | 3 Cars |
| Entry Location: | Front |
Ceiling Heights
| First Floor / 9′ 0″ |
Roof Details
| Primary Pitch: | .25 on 12 |
| Framing Type: | Truss |
View More Details About This Floor Plan
Plan 370005SEN
Visitors enter a magnificent entrance through a courtyard, where a coat closet is located. The great room, kitchen, and dining area are all connected in an open floor plan that welcomes you down the hall. The spacious prep island will be appreciated by the family’s chef, and the walk-in pantry provides enough of storage. The communal living area is situated to benefit from the covered terrace and backward views.
A fourth bedroom or office with a half bathroom is accessible through French doors off the great area. While the rear-facing master suite has a tray ceiling, a 5-fixture bathroom, and a sizable walk-in closet, the other two bedrooms share a hall bathroom. A large rooftop patio may be built on a contemporary flat roof for optimal outdoor pleasure.
